Hello, cybersecurity enthusiasts and white hackers!

code injection

In the previous posts I wrote about DLL injection via undocumented NtCreateThreadEx and NtAllocateVirtualMemory.

The following post is a result of self-research of malware development technique which is interaction with the undocumented Native API.

Today I tried to replace another function OpenProcess with undocumented Native API function NtOpenProcess.

First of all, let’s take a look at function NtOpenProcess syntax:

__kernel_entry NTSYSCALLAPI NTSTATUS NtOpenProcess(
  [out]          PHANDLE            ProcessHandle,
  [in]           ACCESS_MASK        DesiredAccess,
  [in]           POBJECT_ATTRIBUTES ObjectAttributes,
  [in, optional] PCLIENT_ID         ClientId
);

Here it is worth paying attention to the ObjectAttributes and ClientId parameters. ObjectAttributes - a pointer to an OBJECT_ATTRIBUTES structure that specifies the attributes to apply to the process object handle. This has to be defined and initialized prior to opening the handle. ClientId - a pointer to a client ID that identifies the thread whose process is to be opened.

In order to use NtOpenProcess function, we have to define its definition in our code:

code injection 2

Similarly, OBJECT_ATTRIBUTES and PCLIENT_ID need to be defined. These structures are defined under NT Kernel header files.

We can run WinDBG in local kernel mode and run:

dt nt!_OBJECT_ATTRIBUTES

code injection 2.2

code injection 2.3

Then run:

dt nt!_CLIENT_ID

code injection 2.4

code injection 2.5

and:

dt nt!_UNICODE_STRING

code injection 2.5.1

code injection 2.5.2

There is one more caveat. Before returning the handle by the NtOpenProcess function/ routine, the Object Attributes need to be initialized which can be applied to the handle. To initialize the Object Attributes an IntitializeObjectAttributes macro is defined and invoked which specifies the properties of an object handle to routines that open handles.

code injection 2.5.3

code injection 2.5.4

IntitializeObjectAttributes

Then, loading the ntdll.dll library to invoke NtOpenProcess:

code injection 3

And then get starting addresses of the our functions:

code injection 4

And finally open process:

code injection 5

And otherwise the main logic is the same.

code injection 6

As shown in this code, the Windows API call OpenProcess can be replaced with Native API call function NtOpenProcess. But we need to define the structures which are defined in the NT kernel header files.

The downside to this method is that the function is undocumented so it may change in the future.

Let’s go to see our simple malware in action. Compile hack.cpp:

x86_64-w64-mingw32-g++ hack.cpp -o hack.exe -mconsole -I/usr/share/mingw-w64/include/ -s -ffunction-sections -fdata-sections -Wno-write-strings -fno-exceptions -fmerge-all-constants -static-libstdc++ -static-libgcc -fpermissive

code inection 7

Then, run process hacker 2:

code injection 8

For example, the highlighted process mspaint.exe is our victim.

Let’s run our simple malware:

.\hack.exe 4964

code injection 9

As you can see our meow-meow messagebox is popped-up.

Let’s go to investigate properties of our victim process PID: 4964:

code injection 10

As you can see, our meow-meow payload successfully injected as expected!

As you can see the main logic is the same with previous NT API function call techniques but there is a caveat with defining the structures and associated parameters. Without defining this structures the code will not run.

The reason why it’s good to have this technique in your arsenal is because we are not using OpenProcess which is more popular and suspicious and which is more closely investigated by the blue teamers.

Let’s go to upload our new hack.exe with encrypted command to Virustotal (13.12.2021):

code injection 11

https://www.virustotal.com/gui/file/9f4213643891fc14473948deb15077d9b7b4d2da3db467932e57e7e383e535e6?nocache=1

So, 5 of 65 AV engines detect our file as malicious.

If we want, for better result, we can add payload encryption with key or obfuscate functions, or combine both of this techniques.

I hope this post spreads awareness to the blue teamers of this interesting technique, and adds a weapon to the red teamers arsenal.

WinDBG kernel debugging
VirtualAllocEx
NtOpenProcess
NtAllocateVirtualMemory
WriteProcessMemory
CreateRemoteThread
source code in Github

This is a practical case for educational purposes only.

Thanks for your time and good bye!
